HV-150A

Vickers Hardness Tester

Main functions

Frictionless loading shaft, high precision testing force.
Automatic testing process, no human operating error.
Precision conforms to GB/T 4340.2, ISO 6507-2 and ASTM E92.

It’s suitable to determine the Vickers hardness of steel, non-ferrous metals, ceramics and treated layers of metal surface, etc.

Main specification

1. Measuring range: 5-2900HV

2. Test force: 9.807, 49.03, 98.07, 196.1, 294.2, 490.3N

(1, 5, 10, 20, 30, 50kgf)

3. Max. height of test piece: 180mm

4. Depth of throat: 125mm

5. Magnifications of the measuring system: 125X, 250X

6. Min. scale value of the optical micrometer: 1μm

7. Power supply: 220V AC or 110V AC, 50 or 60Hz

8. Dimensions: 580 x 260 x 730mm

9. Weight: 90kg
