210HBS-3000

Digital Display Brinell Hardness Tester

Main functions
Digital display of Hardness value.
Manual turret, weight loading system.
Automatic test process, no human operating error.
Large LCD display of testing process, easy operation.
Precision conforms to GB/T 231.2, ISO 6506-2 and ASTM E10.
It's suitable to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc.

Main specification

1. Measuring range: 4-650HBW

2. Test force: 1838.8, 2451.8, 4903.5, 7355.3, 9807, 29421N

(187.5、250、500、750、1000、3000kgf)

3. Max. height of test piece: 280mm

4. Depth of throat: 150mm

5. Optical magnification: 20X, 40X

6. Power supply: 220V AC or 110V AC, 50 or 60Hz

7. Dimensions: 570 x 330 x 910mm

8. Weight: Approx. 220kg　
