Digital Display Vickers Hardness Tester
Main functions
Frictionless loading shaft, high precision testing force.
LCD display, menu operating, complete function with data processing, hardness value conversion and so on.
Precision conforms to GB/T 4340.2, ISO 6507-2 and ASTM E92.
It’s suitable to determine the Vickers hardness of steel, non-ferrous metals, ceramics and treated layers of metal surface, etc.
Main specification
1. Measuring range: 5-2900HV
2. Test force: 9.807, 49.03, 98.07, 196.1, 294.2, 490.3N
(1, 5, 10, 20, 30, 50kgf)
3. Max. height of test piece: 180mm
4. Depth of throat: 125mm
5. Magnifications of the measuring system: 125X, 250X
6. Min. scale value of the optical micrometer: 0.06μm
7. Power supply: 220V AC or 110V AC, 50 or 60Hz
8. Dimensions: 580 x 260 x 730mm
9. Weight: 90kg
