Automatic Turret Vickers Hardness Tester
Main functions
HV-30Z Automatic Turret Vickers Hardness Tester adopts unique precision design in mechanical, optical and light sources, making indentation imaging clearer and measurement more accurate.
Adopts the color liquid crystal display screen, the high speed 32 bit microprocessor control system, fully realizes the man-machine dialogue and the automation operation.It has the characteristics of high test precision, simple operation, high sensitivity, convenient use, stable value and so on.The test force is applied by electronic closed-loop control; The test force can be automatically applied, maintained, removed and the hardness value can be directly displayed.
Main specification
Model | HV-30Z | |
Test range | 5-3000HV | |
Test force | Load method | Weight loading 0.3、0.5、1.0、5.0、10.0、30.0kgf |
Data entry method | Manual | |
Turret way | Automatic | |
Specimen allow max height | 200mm | |
Distance between head center and machine wall | 130mm | |
Lens ratio | 10×, 40× | |
Amplification factor | 100×, 400× | |
Minimum step distance | 0.025μm | |
Hardness resolution | 0.1HV | |
Power supply | AC 220V,50Hz | |
Dimensions | 620*330*650mm | |
Weight | 75kg |
