Digital Brinell Hardness Tester
Main functions
1. HB-3000ET digital Brinell hardness tester, the indentation can be measured directly through the micrometer eyepiece, the diameter and hardness value can be displayed on the LCD screen. Test force, indenter type, holding time and the conversion unit can be displayed and set;
2. The machine body is integral casting by high quality cast iron,, with the automotive paint treatment process, the appearance is round and beautiful;
3. The accuracy is in line with GB/T231.2-2018, ISO6506-2 and American ASTM E10 standard.
Main specification
Model | HB-3000ET |
Range of Measurement | 5-650HBW |
Test Force | 612.9、980.7、1225.9、1838.8、2451.8、4903.5、7355.3、9807、14710.5、29421N(62.5、100、125、187.5、250、500、750、1000、1500、3000kgf) |
Available Maximum Height of Specimen | 330mm |
Beeline between Indenter Center and Wall | 150mm |
Hardness Resolution | 0.1HBW |
Power Supply | AC 220V,50Hz |
Outline Dimension | 700*268*980mm |
Weight | 160kg |
