Vickers Hardness Tester
Main functions
Precision conforms to GB/T 4340.2, ISO 6507-2 and ASTM E384.
It's suitable to determine the Vickers hardness of steel, non-ferrous metals, ceramics, treated layers of metal surface, and the hardness grads of carburized, nitrided and hardened layers of metals. It is and also suitable to determine the Vickers hardness of micro and super thin parts.
Main specification
1. Measuring range: 5-3000HV
2. Test force: 1.961, 2.942, 4.903, 9.807, 19.61, 24.52, 29.42, 49.03N
(0.2, 0.3, 0.5, 1, 2, 2.5, 3, 5kgf)
3. Hardness scale: HV0.2, HV0.3, HV0.5, HV1, HV2, HV2.5, HV3, HV5
4. Measuring accuracy of micrometer: ±0.25μm
5. Test force dwelling time: 0~99 seconds
6. Optical system:
Objective lens: 10X (for observation), 40X (for measurement)
Ocular lens: 12.5X
Total magnification: 125X (for observation), 500X (for measurement)
7. Max. Height of specimen: 75mm
8. Depth of throat: 110mm
9. Size of XY coordinate worktable: 100×100mm
10. Travel of XY coordinate worktable: 25×25mm
11. Resolution of XY coordinate worktable: 0.01um
12. Optical source: 12V/20W
13. Language: Chinese/English
14. Power supply: 220V/110V, 50Hz/60Hz
15. Power consumption: ≤50W
16. Overall dimensions: 486×337×657mm
17. Weight: 68 kg
