Manual Metallographic Sample Cutting Machine (100mm)
Main functions
LQ-120S metallographic sample cutting machine is a manual metallographic sample cutting machine produced by our company. It is mainly used for cutting metallographic samples and cutting and cutting various materials. It is widely used in metallurgy, automobile, aerospace and other manufacturing industries. After the 1990s, the metallographic sample preparation technology has developed rapidly, and the metallographic sample cutting machine as the metallographic sampling equipment has also made great progress.
LQ-120S metallographic sample cutting machine can be used in metallurgical, lithofacies material cutting, waterproof motor with low noise, in order to ensure the safety state of incised to take sample, the machine adopts closed double shield shell structure and professional clamping device, and pay a cooling water tank (environmental protection), can make the configured coolant for cycle use, to prolong the service life and convenient operation and maintenance, etc.
Main specification
Shell | Stainless steel |
Effective depth | 100mm |
Cutting table size | 230X240mm |
Cutting sheet specification | 300mm×2mm×32mm |
Specification of blessing platform | stationary type |
cutting ways | Manual |
Method | Cut type |
Cooling system | Automatic (water-cooled 2 channel) |
Tank capacity | 50L |
Speed of mainshaft | 2800r/min |
Motor power | 2.2KW |
Weight | 85kg |
