Computer Control Automatic Compression Testing Machine
Main functions
YAW-600 Computer control automatic compression testing machine is mainly used for the test brick, stone, cement, concrete and other materials’ compressive strength and compressive properties.
Inside the tank of hydraulic oil through the motor drive the high pressure pump into the oil, through the single-direction valve, high pressure filter, differential pressure valve group, the servo valve, into the cylinder. Computer control signal to the servo valve, control the opening and the direction of servo valve, to control the enter flow of the oil cylinder, and come true the control of constant speed test force.
Main specification
The max force | 600kN |
Test force range | 4% -100% FS |
Test Force relative error | ≤ ± 1% |
Test Force Resolution | 0.01kN |
Rated pressure hydraulic pump | 40MPa |
Upper and lower bearing plate size | 300 × 300mm |
Maximum distance the upper and lower plate | 330mm |
Piston diameter | φ 250mm |
Piston stroke | 50mm |
Motor Power | 0.75 kW, 3 phase |
Weight | 1600kg |
