Computer Control Full Automatic Compression Testing Machine
Main functions
Computer Control Full Automatic Concrete Compression Testing Machine is one automatic computer control electro servo hydraulic compression testing machine. It adopts automatic electro servo hydraulic control for compressing concrete and cement bricks. It is mainly used in compressive strength test of materials such as cement, concrete, brick, stone and other materials.
The whole closed-loop automatic control system is consisted of a microcomputer and the electro-hydraulic control components, it can complete the testing process according to the stress rate or settled curve form.It has dynamic display function for Load/stress rate, time and test curves. Test parameters once set, the machine can automatically complete all tests of a group of specimens.It can print test data and curves when test is over.
Main specification
Model | YAW-1000D |
Maximum Load | 1000kN |
Effective testing range | 2%-100%FS |
Relative error of loading value | ≤±1% |
Test force solution | 1/300000 of the maximum deformation |
Host structure | Four column, whole rigidity structure without clearance |
Dimension of upper Plate and lower Plate | Φ300mm or 420*420mm |
Largest compression space | 300mm |
Piston movement speed | 80mm/min |
Adjustment method of upper and lower plate | Large stroke oil cylinder |
Test force loading rate | 0.02%—2%FS/s |
Two-way oil cylinder stroke | 200mm |
Effective distance between the two columns | 420*420mm |
Outline dimension | 550×550×1650mm |
Power supply | 3-phase, 380V, 50Hz (or specified by users) |
Weight | 2300kg |
