Computerized Metallographic Microscope
Main functions
This model is a three-mesh inverted metallographic microscope, which is used to identify and analyze the combined structure of various metals and alloy materials. It is widely used in the factory or laboratory for casting quality identification, raw material inspection or metallographic structure analysis after material treatment, as well as for surface spraying and other surface phenomena.
It is an effective means for the metallographic analysis of iron and steel, non-ferrous metal materials, castings and coatings, the petrographic analysis of geology, as well as the microcosmic research of compounds and ceramics in the industrial field.
Main specification
Optical system | Optical system with finite chromatic aberration |
Observing tube | 45° tilt, three-eye observation cylinder, pupil distance adjustment range :54-75mm, spectral ratio: 80:20 |
Eyepiece | High eye spot wide field flat field eyepiece PL10X/18mm |
Objective (long achromatic lens) | LMPL5X /0.13 WD15.5mm |
LMPL10X/0.25 WD8.7mm | |
LMPL20X/0.40 WD8.8mm | |
LMPL50X/0.60 WD5.1mm | |
Transverter | Internal positioning four-hole converter |
Focusing mechanism | Coaxial focusing mechanism is coarsely fine-tuned with low hand position, and the stroke of each revolution is 38 mm. Fine tuning precision 0.02mm |
Objective table | Three layers of mechanical mobile platform, the area 180 mmx155mm, right hand control, low stroke: 75 mm x 40 mm |
Working table | Metal slide counter (central hole Φ 12 mm) |
Fall lighting system | Colla lighting system with variable aperture light bar and center adjustable field light bar, adaptive wide voltage 100V-240V, a single 5W warm color LED lamp, continuous adjustable light intensity |
Color filter | Yellow, green, blue and frosted color filter |
Metallographic analysis system | FMIA2020 genuine metallographic analysis software, Sony chip 3 million camera device, 0.5X adapter mirror interface, micrometer. |
