Computer Control Static Load Anchoring Performance Testing Machine
Main functions
This series of products are mainly used for static anchoring and low cycle load performance test of steel strand anchor in railway bridge, water conservancy, electric power and other infrastructure construction. It is suitable for GB/T14370 "Anchors, Fixtures and Connectors for Prestressed Tendons" mechanical properties test to judge whether the mechanical properties of steel strand anchors can meet the specified requirements.
This series of products are using microcomputer automatic control, automatic acquisition, storage, processing the test data, the computer screen and real-time display in the process of experiment test curve, to detect the change of strength and displacement, automatic computing shrank and print test curve and test data.
Main specification
Model | MGA-6500 |
Capacity | 6500kN |
Effective measuring range | 2%-100%FS |
Relative error of test force | ±1% |
Displacement measuring range | 0-200mm |
Relative error of displacement indication | ±1% |
Force rate control adjustment range | 1MPa--52MPa |
Force rate control relative error | ±1% |
Displacement rate control relative error | ±1% |
Force, displacement to maintain the control range | 0.3%--100%F.S |
Force and displacement keep control relative error | ±1% |
Repeatability | ±0.5% |
Relative resolution | ±0.5% |
Piston stroke | 200mm |
Tensile space | 3200mm |
Dimensions | 3300×750×660mm |
Weight | 5000kg |
