Computer Controlled Friction and Wear Testing Machine
Main functions
This machine mainly used for horizontal reciprocating friction and wear test of ball friction pair (pin - piece, ball - piece reciprocating in straight line). It can also be used for reciprocating friction and wear test of other forms of friction pair by changing fixture.
It can be used in dry friction, drip lubrication and oil-lubricated state experiments to determine the friction and wear characteristics of different materials and different surface treatment of friction pair materials. Suitable for colleges and universities, scientific research institutes, quality supervision and inspection departments.
Main specification
1. Max testing force: 30N
2. Application of test force: weight loading
3. Maximum reciprocating test stroke: ±25mm (adjustable)
4. Sample ball: φ10mm
5. Sample piece: 60×30×3mm
6. The realization way of reciprocating motion: crank connecting rod mechanism and screw adjust eccentricity
7. Reciprocating test frequency range: 0-15Hz
8. Measurement range of friction: ±30N
9. Machine dimension: (length × width × height) 800×550×1050mm
10. Power supply: 220V、50Hz、0.75 KW
11. Weight: 300KG
